At Siddheswari Corporation, we are a leading redial drill machine supplier in Gujarat. We manufacture, supply and export a varied range of heavy duty radial drilling machines featuring optimum quality and exceptional strength. All our machines are designed using quality tested materials and are widely used to deliver stable performance during drilling processes. They are treasured by our clients for their optimum performance and flawless operations for longer hours.

Since inception, we are known for offering superior quality All Geared Radial drill Machines to our valuable clients. Backed by cutting edge technology, our drilling machines are the smoothest running in the industry and perform operations with high accuracy. Besides their optimum quality, they are acclaimed for high tensile strength and exceptional features. This has made us the leading radial drill machine supplier in Gujarat.

We are not just a leading supplier but also one of the top radial drilling machine manufacturers. With firm commitment to quality and excellence, we design and manufacture high Precision Heavy duty Redial drill Machine, Fine feed Redial drill Machine, Auto feed radial drill machines. Our radial drilling machines are available in various specifications, sizes, shapes as per the requirements of our clients. Being a leading and responsible radial drilling machine manufacturer, we provide cost effective and reliable solutions for even the most complex projects. Be it the engineering or automobile industry or any other, we always comply with the accuracy and quality demands of all our customers. Our range of advanced Lathe machines has helped us achieve the satisfaction and trust of our valuable clients.

Pillar Drill Machine Specification : 25mm.40mm.

Technical Specification	25 mm Redial Drill	40 mm Redial Drill
Drill capacity	25 mm	40 mm
Pillar diameter	130 mm	165 mm
Spindle nose to table distance	650 mm	705 mm
Distance from spindle nose to base distance	860 mm	850 mm
Distance from spindle center to pillar surface	675 mm	850 mm
Minimum distance from spindle to pillar surface	385 mm	-
Taper in spindle	M.T. - 3	M.T. - 4
Number of speed	8 speed	8 speed
Range of speed (R.P.M)	1095 mm	-
Pillar Height from bas surface	125 to 2800	70 to 2000
Work table size (in mm)	310 × 208 × 208	305 × 305 × 400
Base size (machined area)	620 × 690	730 × 930
Overall base size	620 × 980	730 × 1290
Spindle travel	250 mm	255 mm
Pillar length from bas surface	1330 mm	1400 mm
Overall size	1650 × 1070 mm	1700 mm
Weight (Approx)	470 Kg	825 Kg
V-belt spindle	B-41	B-47
V-belt lifting	A-23	A-24
Type of Feed	Manual	Manual
No. of "T" Slots	3	3

Standard accessories of Redial Drill Machine

• Motor Pulley
• Tapper Drift
• Manual book

Charges of extra accessories of Redial Drill Machine

• Electric Motor
• Key-way compound Slide
• R & F Switch
• Coolant Pump
• Machine Lamp
• Drill Chuck
• Drill Vice
• Arbor
• Motor Belt
